Query VLM with Offline Engine#

This tutorial demonstrates how to use SGLang’s offline Engine API to query VLMs. We will demonstrate usage with Qwen2.5-VL and Llama 4. This section demonstrates three different calling approaches:

Basic Call: Directly pass images and text.
Processor Output: Use HuggingFace processor for data preprocessing.
Precomputed Embeddings: Pre-calculate image features to improve inference efficiency.

Understanding the Three Input Formats#

SGLang supports three ways to pass visual data, each optimized for different scenarios:

1. Raw Images - Simplest approach#

Pass PIL Images, file paths, URLs, or base64 strings directly
SGLang handles all preprocessing automatically
Best for: Quick prototyping, simple applications

2. Processor Output - For custom preprocessing#

Pre-process images with HuggingFace processor
Pass the complete processor output dict with format: "processor_output"
Best for: Custom image transformations, integration with existing pipelines
Requirement: Must use input_ids instead of text prompt

3. Precomputed Embeddings - For maximum performance#

Pre-calculate visual embeddings using the vision encoder
Pass embeddings with format: "precomputed_embedding"
Best for: Repeated queries on same images, caching, high-throughput serving
Performance gain: Avoids redundant vision encoder computation (30-50% speedup)

Key Rule: Within a single request, use only one format for all images. Don’t mix formats.

The examples below demonstrate all three approaches with both Qwen2.5-VL and Llama 4 models.

Querying Qwen2.5-VL Model#

[1]:

import nest_asyncio

nest_asyncio.apply()

model_path = "Qwen/Qwen2.5-VL-3B-Instruct"
chat_template = "qwen2-vl"

[2]:

from io import BytesIO
import requests
from PIL import Image

from sglang.srt.parser.conversation import chat_templates

image = Image.open(
    BytesIO(
        requests.get(
            "https://github.com/sgl-project/sglang/blob/main/examples/assets/example_image.png?raw=true"
        ).content
    )
)

conv = chat_templates[chat_template].copy()
conv.append_message(conv.roles[0], f"What's shown here: {conv.image_token}?")
conv.append_message(conv.roles[1], "")
conv.image_data = [image]

print("Generated prompt text:")
print(conv.get_prompt())
print(f"\nImage size: {image.size}")

Generated prompt text:
<|im_start|>system
You are a helpful assistant.<|im_end|>
<|im_start|>user
What's shown here: <|vision_start|><|image_pad|><|vision_end|>?<|im_end|>
<|im_start|>assistant


Image size: (570, 380)

[2]:

../_images/advanced_features_vlm_query_4_1.png

Basic Offline Engine API Call#

[3]:

from sglang import Engine

llm = Engine(model_path=model_path, chat_template=chat_template, log_level="warning")

[2026-02-23 14:07:36] INFO utils.py:148: Note: detected 128 virtual cores but NumExpr set to maximum of 64, check "NUMEXPR_MAX_THREADS" environment variable.
[2026-02-23 14:07:36] INFO utils.py:151: Note: NumExpr detected 128 cores but "NUMEXPR_MAX_THREADS" not set, so enforcing safe limit of 16.
[2026-02-23 14:07:36] INFO utils.py:164: NumExpr defaulting to 16 threads.
<frozen importlib._bootstrap_external>:1184: FutureWarning: The cuda.cudart module is deprecated and will be removed in a future release, please switch to use the cuda.bindings.runtime module instead.
<frozen importlib._bootstrap_external>:1184: FutureWarning: The cuda.nvrtc module is deprecated and will be removed in a future release, please switch to use the cuda.bindings.nvrtc module instead.
[2026-02-23 14:07:38] INFO server_args.py:1835: Attention backend not specified. Use fa3 backend by default.
[2026-02-23 14:07:38] INFO server_args.py:2886: Set soft_watchdog_timeout since in CI
[2026-02-23 14:07:38] INFO engine.py:156: server_args=ServerArgs(model_path='Qwen/Qwen2.5-VL-3B-Instruct', tokenizer_path='Qwen/Qwen2.5-VL-3B-Instruct', tokenizer_mode='auto', tokenizer_worker_num=1, skip_tokenizer_init=False, load_format='auto', model_loader_extra_config='{}', trust_remote_code=False, context_length=None, is_embedding=False, enable_multimodal=None, revision=None, model_impl='auto', host='127.0.0.1', port=30000, fastapi_root_path='', grpc_mode=False, skip_server_warmup=False, warmups=None, nccl_port=None, checkpoint_engine_wait_weights_before_ready=False, dtype='auto', quantization=None, quantization_param_path=None, kv_cache_dtype='auto', enable_fp32_lm_head=False, modelopt_quant=None, modelopt_checkpoint_restore_path=None, modelopt_checkpoint_save_path=None, modelopt_export_path=None, quantize_and_serve=False, rl_quant_profile=None, mem_fraction_static=0.7486296874999999, max_running_requests=None, max_queued_requests=None, max_total_tokens=None, chunked_prefill_size=8192, enable_dynamic_chunking=False, max_prefill_tokens=16384, prefill_max_requests=None, schedule_policy='fcfs', enable_priority_scheduling=False, abort_on_priority_when_disabled=False, schedule_low_priority_values_first=False, priority_scheduling_preemption_threshold=10, schedule_conservativeness=1.0, page_size=1, swa_full_tokens_ratio=0.8, disable_hybrid_swa_memory=False, radix_eviction_policy='lru', enable_prefill_delayer=False, prefill_delayer_max_delay_passes=30, prefill_delayer_token_usage_low_watermark=None, prefill_delayer_forward_passes_buckets=None, prefill_delayer_wait_seconds_buckets=None, device='cuda', tp_size=1, pp_size=1, pp_max_micro_batch_size=None, pp_async_batch_depth=0, stream_interval=1, stream_output=False, random_seed=1034073686, constrained_json_whitespace_pattern=None, constrained_json_disable_any_whitespace=False, watchdog_timeout=300, soft_watchdog_timeout=300, dist_timeout=None, download_dir=None, model_checksum=None, base_gpu_id=0, gpu_id_step=1, sleep_on_idle=False, custom_sigquit_handler=None, log_level='warning', log_level_http=None, log_requests=False, log_requests_level=2, log_requests_format='text', log_requests_target=None, uvicorn_access_log_exclude_prefixes=[], crash_dump_folder=None, show_time_cost=False, enable_metrics=False, enable_metrics_for_all_schedulers=False, tokenizer_metrics_custom_labels_header='x-custom-labels', tokenizer_metrics_allowed_custom_labels=None, extra_metric_labels=None, bucket_time_to_first_token=None, bucket_inter_token_latency=None, bucket_e2e_request_latency=None, collect_tokens_histogram=False, prompt_tokens_buckets=None, generation_tokens_buckets=None, gc_warning_threshold_secs=0.0, decode_log_interval=40, enable_request_time_stats_logging=False, kv_events_config=None, enable_trace=False, otlp_traces_endpoint='localhost:4317', export_metrics_to_file=False, export_metrics_to_file_dir=None, api_key=None, admin_api_key=None, served_model_name='Qwen/Qwen2.5-VL-3B-Instruct', weight_version='default', chat_template='qwen2-vl', hf_chat_template_name=None, completion_template=None, file_storage_path='sglang_storage', enable_cache_report=False, reasoning_parser=None, tool_call_parser=None, tool_server=None, sampling_defaults='model', dp_size=1, load_balance_method='round_robin', attn_cp_size=1, moe_dp_size=1, dist_init_addr=None, nnodes=1, node_rank=0, json_model_override_args='{}', preferred_sampling_params=None, enable_lora=None, enable_lora_overlap_loading=None, max_lora_rank=None, lora_target_modules=None, lora_paths=None, max_loaded_loras=None, max_loras_per_batch=8, lora_eviction_policy='lru', lora_backend='csgmv', max_lora_chunk_size=16, attention_backend='fa3', decode_attention_backend=None, prefill_attention_backend=None, sampling_backend='flashinfer', grammar_backend='xgrammar', mm_attention_backend=None, fp8_gemm_runner_backend='auto', fp4_gemm_runner_backend='flashinfer_cutlass', nsa_prefill_backend=None, nsa_decode_backend=None, disable_flashinfer_autotune=False, mamba_backend='triton', speculative_algorithm=None, speculative_draft_model_path=None, speculative_draft_model_revision=None, speculative_draft_load_format=None, speculative_num_steps=None, speculative_eagle_topk=None, speculative_num_draft_tokens=None, speculative_accept_threshold_single=1.0, speculative_accept_threshold_acc=1.0, speculative_token_map=None, speculative_attention_mode='prefill', speculative_draft_attention_backend=None, speculative_moe_runner_backend='auto', speculative_moe_a2a_backend=None, speculative_draft_model_quantization=None, speculative_ngram_min_match_window_size=1, speculative_ngram_max_match_window_size=12, speculative_ngram_min_bfs_breadth=1, speculative_ngram_max_bfs_breadth=10, speculative_ngram_match_type='BFS', speculative_ngram_branch_length=18, speculative_ngram_capacity=10000000, enable_multi_layer_eagle=False, ep_size=1, moe_a2a_backend='none', moe_runner_backend='auto', flashinfer_mxfp4_moe_precision='default', enable_flashinfer_allreduce_fusion=False, deepep_mode='auto', ep_num_redundant_experts=0, ep_dispatch_algorithm=None, init_expert_location='trivial', enable_eplb=False, eplb_algorithm='auto', eplb_rebalance_num_iterations=1000, eplb_rebalance_layers_per_chunk=None, eplb_min_rebalancing_utilization_threshold=1.0, expert_distribution_recorder_mode=None, expert_distribution_recorder_buffer_size=1000, enable_expert_distribution_metrics=False, deepep_config=None, moe_dense_tp_size=None, elastic_ep_backend=None, mooncake_ib_device=None, max_mamba_cache_size=None, mamba_ssm_dtype=None, mamba_full_memory_ratio=0.9, mamba_scheduler_strategy='no_buffer', mamba_track_interval=256, enable_hierarchical_cache=False, hicache_ratio=2.0, hicache_size=0, hicache_write_policy='write_through', hicache_io_backend='kernel', hicache_mem_layout='layer_first', disable_hicache_numa_detect=False, hicache_storage_backend=None, hicache_storage_prefetch_policy='best_effort', hicache_storage_backend_extra_config=None, hierarchical_sparse_attention_extra_config=None, enable_lmcache=False, kt_weight_path=None, kt_method=None, kt_cpuinfer=None, kt_threadpool_count=None, kt_num_gpu_experts=None, kt_max_deferred_experts_per_token=None, dllm_algorithm=None, dllm_algorithm_config=None, enable_double_sparsity=False, ds_channel_config_path=None, ds_heavy_channel_num=32, ds_heavy_token_num=256, ds_heavy_channel_type='qk', ds_sparse_decode_threshold=4096, cpu_offload_gb=0, offload_group_size=-1, offload_num_in_group=1, offload_prefetch_step=1, offload_mode='cpu', multi_item_scoring_delimiter=None, disable_radix_cache=False, cuda_graph_max_bs=256, cuda_graph_bs=[1, 2, 4, 8, 12, 16, 24, 32, 40, 48, 56, 64, 72, 80, 88, 96, 104, 112, 120, 128, 136, 144, 152, 160, 168, 176, 184, 192, 200, 208, 216, 224, 232, 240, 248, 256], disable_cuda_graph=False, disable_cuda_graph_padding=False, enable_profile_cuda_graph=False, enable_cudagraph_gc=False, enable_layerwise_nvtx_marker=False, enable_nccl_nvls=False, enable_symm_mem=False, disable_flashinfer_cutlass_moe_fp4_allgather=False, enable_tokenizer_batch_encode=False, disable_tokenizer_batch_decode=False, disable_outlines_disk_cache=False, disable_custom_all_reduce=False, enable_mscclpp=False, enable_torch_symm_mem=False, disable_overlap_schedule=False, enable_mixed_chunk=False, enable_dp_attention=False, enable_dp_lm_head=False, enable_two_batch_overlap=False, enable_single_batch_overlap=False, tbo_token_distribution_threshold=0.48, enable_torch_compile=False, enable_piecewise_cuda_graph=False, enable_torch_compile_debug_mode=False, torch_compile_max_bs=32, piecewise_cuda_graph_max_tokens=8192, piecewise_cuda_graph_tokens=[4, 8, 12, 16, 20, 24, 28, 32, 48, 64, 80, 96, 112, 128, 144, 160, 176, 192, 208, 224, 240, 256, 288, 320, 352, 384, 416, 448, 480, 512, 576, 640, 704, 768, 832, 896, 960, 1024, 1280, 1536, 1792, 2048, 2304, 2560, 2816, 3072, 3328, 3584, 3840, 4096, 4608, 5120, 5632, 6144, 6656, 7168, 7680, 8192], piecewise_cuda_graph_compiler='eager', torchao_config='', enable_nan_detection=False, enable_p2p_check=False, triton_attention_reduce_in_fp32=False, triton_attention_num_kv_splits=8, triton_attention_split_tile_size=None, num_continuous_decode_steps=1, delete_ckpt_after_loading=False, enable_memory_saver=False, enable_weights_cpu_backup=False, enable_draft_weights_cpu_backup=False, allow_auto_truncate=False, enable_custom_logit_processor=False, flashinfer_mla_disable_ragged=False, disable_shared_experts_fusion=False, disable_chunked_prefix_cache=False, disable_fast_image_processor=False, keep_mm_feature_on_device=False, enable_return_hidden_states=False, enable_return_routed_experts=False, scheduler_recv_interval=1, numa_node=None, enable_deterministic_inference=False, rl_on_policy_target=None, enable_attn_tp_input_scattered=False, enable_nsa_prefill_context_parallel=False, nsa_prefill_cp_mode='round-robin-split', enable_fused_qk_norm_rope=False, enable_precise_embedding_interpolation=False, enable_dynamic_batch_tokenizer=False, dynamic_batch_tokenizer_batch_size=32, dynamic_batch_tokenizer_batch_timeout=0.002, debug_tensor_dump_output_folder=None, debug_tensor_dump_layers=None, debug_tensor_dump_input_file=None, debug_tensor_dump_inject=False, disaggregation_mode='null', disaggregation_transfer_backend='mooncake', disaggregation_bootstrap_port=8998, disaggregation_decode_tp=None, disaggregation_decode_dp=None, disaggregation_prefill_pp=1, disaggregation_ib_device=None, disaggregation_decode_enable_offload_kvcache=False, num_reserved_decode_tokens=512, disaggregation_decode_polling_interval=1, encoder_only=False, language_only=False, encoder_transfer_backend='zmq_to_scheduler', encoder_urls=[], custom_weight_loader=[], weight_loader_disable_mmap=False, remote_instance_weight_loader_seed_instance_ip=None, remote_instance_weight_loader_seed_instance_service_port=None, remote_instance_weight_loader_send_weights_group_ports=None, remote_instance_weight_loader_backend='nccl', remote_instance_weight_loader_start_seed_via_transfer_engine=False, enable_pdmux=False, pdmux_config_path=None, sm_group_num=8, mm_max_concurrent_calls=32, mm_per_request_timeout=10.0, enable_broadcast_mm_inputs_process=False, enable_prefix_mm_cache=False, mm_enable_dp_encoder=False, mm_process_config={}, limit_mm_data_per_request=None, decrypted_config_file=None, decrypted_draft_config_file=None, forward_hooks=None)
[2026-02-23 14:07:40] Ignore import error when loading sglang.srt.multimodal.processors.glmasr: cannot import name 'GlmAsrConfig' from 'transformers' (/usr/local/lib/python3.10/dist-packages/transformers/__init__.py)
<frozen importlib._bootstrap_external>:1184: FutureWarning: The cuda.cudart module is deprecated and will be removed in a future release, please switch to use the cuda.bindings.runtime module instead.
<frozen importlib._bootstrap_external>:1184: FutureWarning: The cuda.nvrtc module is deprecated and will be removed in a future release, please switch to use the cuda.bindings.nvrtc module instead.
<frozen importlib._bootstrap_external>:1184: FutureWarning: The cuda.cudart module is deprecated and will be removed in a future release, please switch to use the cuda.bindings.runtime module instead.
<frozen importlib._bootstrap_external>:1184: FutureWarning: The cuda.nvrtc module is deprecated and will be removed in a future release, please switch to use the cuda.bindings.nvrtc module instead.

[Gloo] Rank 0 is connected to 0 peer ranks. Expected number of connected peer ranks is : 0
[Gloo] Rank 0 is connected to 0 peer ranks. Expected number of connected peer ranks is : 0
[Gloo] Rank 0 is connected to 0 peer ranks. Expected number of connected peer ranks is : 0

[2026-02-23 14:07:47] Ignore import error when loading sglang.srt.models.glm_ocr: No module named 'transformers.models.glm_ocr'
[2026-02-23 14:07:47] Ignore import error when loading sglang.srt.models.glm_ocr_nextn: No module named 'transformers.models.glm_ocr'
[2026-02-23 14:07:47] Ignore import error when loading sglang.srt.models.glmasr: cannot import name 'GlmAsrConfig' from 'transformers' (/usr/local/lib/python3.10/dist-packages/transformers/__init__.py)
[2026-02-23 14:07:47] Ignore import error when loading sglang.srt.models.grok: cannot import name '_yarn_find_correction_range' from 'sglang.srt.layers.rotary_embedding' (/actions-runner/_work/sglang/sglang/python/sglang/srt/layers/rotary_embedding/__init__.py)
Loading safetensors checkpoint shards:   0% Completed | 0/2 [00:00<?, ?it/s]
Loading safetensors checkpoint shards:  50% Completed | 1/2 [00:00<00:00,  1.76it/s]
Loading safetensors checkpoint shards: 100% Completed | 2/2 [00:01<00:00,  1.29it/s]
Loading safetensors checkpoint shards: 100% Completed | 2/2 [00:01<00:00,  1.35it/s]

Capturing batches (bs=1 avail_mem=25.48 GB): 100%|██████████| 36/36 [00:01<00:00, 19.22it/s]

[4]:

out = llm.generate(prompt=conv.get_prompt(), image_data=[image])
print("Model response:")
print(out["text"])

Model response:
The image shows a person in a yellow shirt using the back of a yellow taxi to hang clothes on a clothesline. This is an unusual and humorous scene, as the person is utilizing the taxi as a makeshift clothes rack. The background includes tall buildings and a crowded street. The presence of several flags and banners hanging from flying eyes can be seen from other buildings nearby.

Call with Processor Output#

Using a HuggingFace processor to preprocess text and images, and passing the processor_output directly into Engine.generate.

[5]:

from transformers import AutoProcessor

processor = AutoProcessor.from_pretrained(model_path, use_fast=True)
processor_output = processor(
    images=[image], text=conv.get_prompt(), return_tensors="pt"
)

out = llm.generate(
    input_ids=processor_output["input_ids"][0].detach().cpu().tolist(),
    image_data=[dict(processor_output, format="processor_output")],
)
print("Response using processor output:")
print(out["text"])

Response using processor output:
It seems like there is a confusing mix-up here. The original instruction was about "bbcook prjex linee" and "bbb cook key menu", while the received "bbcook prjex linee" and "bbcook key menu" can be interpreted as an instruction to focus on "bbcook prjex" or "bbcook key menu".

My response is out of confusion. Would you like the instruction to be performed or interpreted?

Call with Precomputed Embeddings#

You can pre-calculate image features to avoid repeated visual encoding processes.

[6]:

from transformers import AutoProcessor
from transformers import Qwen2_5_VLForConditionalGeneration

processor = AutoProcessor.from_pretrained(model_path, use_fast=True)
vision = (
    Qwen2_5_VLForConditionalGeneration.from_pretrained(model_path).eval().visual.cuda()
)

[7]:

processor_output = processor(
    images=[image], text=conv.get_prompt(), return_tensors="pt"
)

input_ids = processor_output["input_ids"][0].detach().cpu().tolist()

precomputed_embeddings = vision(
    processor_output["pixel_values"].cuda(), processor_output["image_grid_thw"].cuda()
)

multi_modal_item = dict(
    processor_output,
    format="precomputed_embedding",
    feature=precomputed_embeddings,
)

out = llm.generate(input_ids=input_ids, image_data=[multi_modal_item])
print("Response using precomputed embeddings:")
print(out["text"])

llm.shutdown()

Response using precomputed embeddings:
The image shows a scene on a city street with two yellow taxis. One of the taxis has additional gear strapped to its back by a person in a yellow shirt who is standing beside it. The gear includes items such as towels, a clothes rack, a steamer, and a hanging hook. The gear is used by a fire department to dry, iron, or press clothes quickly in emergency situations, often during floods or storms where conventional washing facilities might be unavailable. The presence of the gear attached to the taxi indicates a practical method of providing emergency clothing care in an unexpected situation, possibly in the aftermath of a hurricane or other disaster.

Querying Llama 4 Vision Model#

model_path = "meta-llama/Llama-4-Scout-17B-16E-Instruct"
chat_template = "llama-4"

from io import BytesIO
import requests
from PIL import Image

from sglang.srt.parser.conversation import chat_templates

# Download the same example image
image = Image.open(
    BytesIO(
        requests.get(
            "https://github.com/sgl-project/sglang/blob/main/examples/assets/example_image.png?raw=true"
        ).content
    )
)

conv = chat_templates[chat_template].copy()
conv.append_message(conv.roles[0], f"What's shown here: {conv.image_token}?")
conv.append_message(conv.roles[1], "")
conv.image_data = [image]

print("Llama 4 generated prompt text:")
print(conv.get_prompt())
print(f"Image size: {image.size}")


Llama 4 Basic Call#

Llama 4 requires more computational resources, so it’s configured with multi-GPU parallelism (tp_size=4) and larger context length.

llm = Engine(
    model_path=model_path,
    enable_multimodal=True,
    attention_backend="fa3",
    tp_size=4,
    context_length=65536,
)

out = llm.generate(prompt=conv.get_prompt(), image_data=[image])
print("Llama 4 response:")
print(out["text"])

Call with Processor Output#

Using HuggingFace processor to preprocess data can reduce computational overhead during inference.

from transformers import AutoProcessor

processor = AutoProcessor.from_pretrained(model_path, use_fast=True)
processor_output = processor(
    images=[image], text=conv.get_prompt(), return_tensors="pt"
)

out = llm.generate(
    input_ids=processor_output["input_ids"][0].detach().cpu().tolist(),
    image_data=[dict(processor_output, format="processor_output")],
)
print("Response using processor output:")
print(out)

Call with Precomputed Embeddings#

from transformers import AutoProcessor
from transformers import Llama4ForConditionalGeneration

processor = AutoProcessor.from_pretrained(model_path, use_fast=True)
model = Llama4ForConditionalGeneration.from_pretrained(
    model_path, torch_dtype="auto"
).eval()

vision = model.vision_model.cuda()
multi_modal_projector = model.multi_modal_projector.cuda()

print(f'Image pixel values shape: {processor_output["pixel_values"].shape}')
input_ids = processor_output["input_ids"][0].detach().cpu().tolist()

# Process image through vision encoder
image_outputs = vision(
    processor_output["pixel_values"].to("cuda"),
    aspect_ratio_ids=processor_output["aspect_ratio_ids"].to("cuda"),
    aspect_ratio_mask=processor_output["aspect_ratio_mask"].to("cuda"),
    output_hidden_states=False
)
image_features = image_outputs.last_hidden_state

# Flatten image features and pass through multimodal projector
vision_flat = image_features.view(-1, image_features.size(-1))
precomputed_embeddings = multi_modal_projector(vision_flat)

# Build precomputed embedding data item
mm_item = dict(
    processor_output,
    format="precomputed_embedding",
    feature=precomputed_embeddings
)

# Use precomputed embeddings for efficient inference
out = llm.generate(input_ids=input_ids, image_data=[mm_item])
print("Llama 4 precomputed embedding response:")
print(out["text"])
